Product Description
IP Office 9.0

© 2014 AVAYA All rights reserved.

Page 445

Issue 27.02.0 (Monday, January 06, 2014)

The Avaya Softphone (part of Teleworker and Power User packages) checks if there is a Preferred Edition
license.

Top 10 cryptocurrencies by market cap

If there is none it sends an appropriate alarm to the administrator explaining that Preferred Edition
license was not found.

Trunk Licenses

SIP Trunk Channel Licenses

These licenses are used to enable channels on SIP trunks added to the IP Office system.

When a channel is
used it requires a license. Multiple licenses can be combined for the total number of channels required. Note
that SIP calls may require VCM channels.

Ipo r9+ sip trnk 10 adi lic

See IP Office Manager for more information.

· SIP Trunk Channels - 1 Channel: IPO R9 SIP TRNK 1 ADI LIC (275659)

· SIP Trunk Channels - 5 Channels: IPO R9 SIP TRNK 5 ADI LIC (275660)

· SIP Trunk Channels - 10 Channels: IPO R9 SIP TRNK 10 ADI LIC (275661)

· SIP Trunk Channels - 20 Channels: IPO R9 SIP TRNK 20 ADI LIC (275662)

IP Office 500 System Licenses

IP500 Universal PRI Additional Channel Licenses

The IP500 PRI Universal trunk card (IP500 PRI-U) is available in 1 or 2 port variants, each port supporting a
single PRI trunk connection.

Through the IP Office configuration the ports can be switched between supporting
E1, E1R2 or T1 line types as required for the trunk being connected.

Ipo r9+ sip trnk 10 adi lic

Each port supports 8 B-channels
("Bearer") which do not need to be licensed. If additional B-channels are required, they must be licensed
through the addition of the licenses below. Multiple licenses can be added to achieve the total number of
channels required.

Avaya IP Office SIP Trunk ADI Licenses

D-channels are not subject to licensing. The licenses are consumed by those channels which
are configured as being 'in service', in order of the installed IP500 PRI-U cards.

Avaya IP Office 500v2 SIP Trunk Configuration on SIP.US

IP500 Universal PRI Additional E1 Channels Licenses
These licenses are used to enable additional E1 B-channels for IP500 PRI-U cards configured for E1 operation.
Each port can support up to 30 B-channels in this mode.

· IP500 Universal PRI Additional Channels - 2 E1 Channels License: IPO R9 IP500 E1 ADD 2CH ADI LIC

(275634)

· IP500 Universal PRI Additional Channels - 8 E1 Channels License: IPO R9 IP500 E1 ADD 8CH ADI LIC

(275635)

· IP500 Universal PRI Additional Channels - 22 E1 Channels License: IPO R9 IP500 E1 ADD 22CH ADI LIC

(275633)

IP500 Universal PRI Additional E1R2 Channel Licenses
These licenses are used to enable additional E1R2 B-channels for IP500 PRI-U cards configured for E1R2
operation.

Each port can support up to 30 B-channels in this mode.

Ipo r9+ sip trnk 10 adi lic

· IP500 Universal PRI Additional Channels - 2 E1R2 Channels License: IPO R9 IP500 E1R2 ADD 2CH ADI

LIC (275637)

· IP500 Universal PRI Additional Channels - 8 E1R2 Channels License: IPO R9 IP500 E1R2 ADD 8CH ADI

LIC (275638)

· IP500 Universal PRI Additional Channels - 22 E1R2 Channels License: IPO R9 IP500 E1R2 ADD 22CH

ADI LIC (275636)

IP500 Universal PRI Additional T1 Channel Licenses
These licenses are used to enable additional T1 B-channels for IP500 PRI-U cards configured for T1 PRI or T1
robbed-bit operation.

Each port can support up to 23 B-channels (T1 PRI) or 24 B-channels (T1 robbed bit) in
these mode.

· IP500 Universal PRI Additional Channels - 2 T1 Channels License: IPO R9 IP500 T1 ADD 2CH ADI LIC

(275639)

· IP500 Universal PRI Additional Channels - 8 T1 Channels License: IPO R9 IP500 T1 ADD 8CH ADI LIC

(275641)

· IP500 Universal PRI Additional Channels - 32 T1 Channels License: IPO R9 IP500 T1 ADD 32CH ADI LIC

(275640)
